13 Technical data

106
13 Technical data
Items
Measuring Range
Density Limits
Accuracy
Sensitivity
Resolution
Self-diagnostic Function
Input/Output
Motion Delay
Power
Power Consumption
Surge Protection
Ambient Temperature
Liquid Temperature
Displacer Speed
Display
Operation
Calibration
Weight
Degree of Protection
Ex Approval
Additional Certificates
Descriptions
0 to 16, 22, 26, 36, or 47m depending on material specification
(47m or more can be ordered depending on conditions.)
3
0.430 to 2.000 g/cm (g/ml) (430 to 2000 kg/m
*1
Level: +/- 0.7mm (0.027 inch)
Interface: +/- 2.7mm (0.106 inch)
3 *3
Density: +/- 0.005 g/cm
+/- 0.1mm (0.004 inch)
+/- 0.1 mm (0.004 inch)
CPU system health, measuring wire tension, communication, gauge
status, level data input, etc
Refer to "2.2 Ordering Information" .
0 to 9.9 seconds (configurable in 100 milliseconds steps)
85 to 264 VAC, 50/60 Hz
20 to 62 VDC, or 20 to 55 VAC, 50/60Hz
Maximum 50 VA / 50 W
Standard supply
-20 to 60 ºC (-4 to 140ºF)
-40 to 60 ºC (-40 to 140ºF) ATEX approval cold temperature version
-200 to +200ºC (-328 to +392ºF)
Max. 2500mm/min
Backlight LCD, level, temperature, status, diagnostics, menu-navigation,
in English, Japanese and Chinese
Local operation by optical display keypad, external contact
Optical display keypad for tank level and sensor adjustment by automated
software routine
12kg (Aluminum drum housing NMS5-1, 5-4)
27kg (Stainless steel drum housing NMS5-2, 5-5, 5-6)
IP67 / NEMA4X
Waterproof and Dustproof , IP67 NEMA 4X
TIIS Ex d IIB T4
FM XP Cl. I Div. 1 Gr. C-D
FM XP-AIS Cl. I Div.1 Gr. C-D
CSA Cl. I Div. 1 Gr. C-D
CSA Ex d[ia] Cl. I Div. 1 Gr. C-D
ATEX II 1/2G Ex d IIB T6-T3
ATEX II 1/2G Ex d IIC T6-T3
ATEX II 1/2G Ex d IIB T6-T3, -40°C
ATEX II 1/2G Ex d (ia) IIB T6-T3
ATEX II 1/2G Ex d (ia) IIB T6-T3, -40°C
IEC Ex d ia IIB T6-T3 Ga/Gb
IEC Ex d IIB T6-T3 Ga/Gb
IEC Ex d IIC T6-T3 Ga/Gb
IEC Ex d ia IIB T6-T3 Ga/Gb, -40°C
IEC Ex d IIB T6-T3 Ga/Gb, -40°C
NEPSI Ex d ia IIB T6-T3
NEPSI Ex d IIB T6-T3
NEPSI Ex d IIC T6-T3
NEPSI Ex d ia IIB T6-T3, -40°C
NEPSI Ex d IIB T6-T3, -40°C
Weights and Measures for custody transfer : NMi, PTB
Overspill prevention : TÜV Nord
SIL (Functional Safety Manual): TÜV Nord
Proservo NMS5
3
)
*2
