5.5

Mounting NMS5 with guide wire

It is also possible to guide the displacer by a guide wire to prevent swinging.
A
B
C
D
Figure 21: Mounting with guide wire, unit of measurement: mm (in)
No.
A Calibration chamber
B Spring and sleeve
C Guide wire sleeve
D Crimp tool
1 NMS5
2 Reducer plate (for low pressure: 6mm (0.236 in))
Reduce flange (material is selectable from SS400 an SUS304.)
3 Spring, SUS304
4 Sleeve, SUS316
5 Calibration chamber for maintenance
NHC4HP for high pressure, SCS13 equivalent to SUS304
NHC4LP for low pressure, SCS13 equivalent to SUS304
6 Tank
7 Measuring wire
8 Guide wire, SUS316
9 Displacer
10 Anchor hook plate, SUS304
13
12
Description
5 Installation
1
2
3
4
5
6
7
8
9
100
10
11
