Proservo NMS5
Item
E
Displacer set: ok?
E
-
Displacer on: E & +
Figure 102: Calibration 4-B
OFF
WEIGHT CALIB.
Figure 103: Calibration 5-B
Endress+Hauser
12. Remove the 50xg wight from the displace and mount
the displacer on the wire.
13. Press "E" at Displacer set: ok?.
14. Press "E" and "+" keys together at "Displacer on: E & "+".
15. OFF is displayed at WEIGHT CALIB. of GVH373.
16. Check GVH370 = GVH342 +/- 2.0 grams.
E
17. If not, adjust sensor or calibrate the weight again.
Procedure
12 Adjustment
Remark
• Calibration starts automatically,
which takes approximately 10
minutes.
• Always enter N = -.
