Figure 52: Static matrix
Figure 53: Touch control
Upper Density
Middle Density
Water Dip
Density Bottom
Figure 54: Operation of displacer
Endress+Hauser
7.5

Operation of displacer

The operation of the displacer for level, bottom level, interface level, and density measurement is pos-
sible by touch control.
1. Select function groupGVH020 OPERA-
TION
2. Select item OPERATION. The LCD shows
the
command given to NMS5and the dis-
placer position.
3. The following commands are available at
this position:
• LEVEL
• UP
• STOP
• BOTTOM LEVEL
• UPPER INTERF. LEV*
• MIDD.INTERF.LEV*
• UPPER DENSITY*
• MIDDLE DENSITY*
• DENSITY BOTTOM*
Level
• WATER DIP*
• REPEATABILITY TEST
• Interface and density measurements are
not available unless
Upper Interface
specifically requested.
Level
• Density profile
measurement is explained in section "8.6
Density and Density Profile Measure-
ments".
Middle Interface
Level
Bottom Level
Procedure
• Set access code to 50.
• If editing has previously been enabled by a
• The optional operation commands are
7 Operation
Remarks
valid access code, then the request for the
code will not appear.
available when such options are set.
57
