tecan NanoQuant Plate Quick Manual page 20

Typical performance values Infinite 200 PRO
Wavelength absorbance
Wavelength accuracy
Wavelength reproducibility
Absorbance bandwidth Infinite M200 PRO
Absorbance bandwidth Infinite F200 PRO
Measurement absorbance
Detection limit (DNA concentration)
Reproducibility of one sample (50 μg/ml)
Ratio 260/280 (50 μg/ml)
Precision @ 260 nm
Accuracy @ 260 nm
Figure 13: Technical drawing of the NanoQuant Plate (dimensions in mm)
20 Quick Guide NanoQuant Plate
< ± 0.5 nm for λ > 315 nm
< ± 0.3 nm for λ ≤ 315 nm
< ± 0.5 nm for λ > 315 nm
< ± 0.3 nm for λ ≤ 315 nm
< 5 nm for λ ≤ 315 nm
< 9 nm for λ > 315 nm
Depending on filters used
1 ng/μl dsDNA
< 1 % CV
± 0.07
< 0.2 %
< 0.5 %
TM
No.30035094 Rev No. 1.4 2013-06
