#GPIO LCD
set_property PACKAGE_PIN L22
set_property IOSTANDARD LVCMOS33 [get_ports LCD_DB7_LS]
set_property PACKAGE_PIN M25
set_property IOSTANDARD LVCMOS33 [get_ports LCD_DB6_LS]
set_property PACKAGE_PIN M24
set_property IOSTANDARD LVCMOS33 [get_ports LCD_DB5_LS]
set_property PACKAGE_PIN L25
set_property IOSTANDARD LVCMOS33 [get_ports LCD_DB4_LS]
set_property PACKAGE_PIN L20
set_property IOSTANDARD LVCMOS33 [get_ports LCD_E_LS]
set_property PACKAGE_PIN L24
set_property IOSTANDARD LVCMOS33 [get_ports LCD_RW_LS]
set_property PACKAGE_PIN L23
set_property IOSTANDARD LVCMOS33 [get_ports LCD_RS_LS]
#GPIO LEDs
set_property PACKAGE_PIN R26
set_property IOSTANDARD LVCMOS33 [get_ports GPIO_LED_3]
set_property PACKAGE_PIN T25
set_property IOSTANDARD LVCMOS33 [get_ports GPIO_LED_2]
set_property PACKAGE_PIN T24
set_property IOSTANDARD LVCMOS33 [get_ports GPIO_LED_1]
set_property PACKAGE_PIN M26
set_property IOSTANDARD LVCMOS33 [get_ports GPIO_LED_0]
#GPIO DIP SW
set_property PACKAGE_PIN R6
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN R7
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN P8
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN R8
set_property IOSTANDARD SSTL15
#GPIO PUSHBUTTON SW
set_property PACKAGE_PIN P6
set_property IOSTANDARD LVCMOS15 [get_ports GPIO_SW_N]
set_property PACKAGE_PIN T5
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN R5
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN U6
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN U5
set_property IOSTANDARD SSTL15
set_property PACKAGE_PIN U4
set_property IOSTANDARD LVCMOS15 [get_ports CPU_RESET]
#GPIO ROTARY SWITCH
set_property PACKAGE_PIN N21
set_property IOSTANDARD LVCMOS33 [get_ports ROTARY_PUSH]
set_property PACKAGE_PIN N22
set_property IOSTANDARD LVCMOS33 [get_ports ROTARY_INCA]
set_property PACKAGE_PIN P20
set_property IOSTANDARD LVCMOS33 [get_ports ROTARY_INCB]
www.xilinx.com
AC701 Board XDC File Listing
[get_ports LCD_DB7_LS]
[get_ports LCD_DB6_LS]
[get_ports LCD_DB5_LS]
[get_ports LCD_DB4_LS]
[get_ports LCD_E_LS]
[get_ports LCD_RW_LS]
[get_ports LCD_RS_LS]
[get_ports GPIO_LED_3]
[get_ports GPIO_LED_2]
[get_ports GPIO_LED_1]
[get_ports GPIO_LED_0]
[get_ports GPIO_DIP_SW3]
[get_ports GPIO_DIP_SW3]
[get_ports GPIO_DIP_SW2]
[get_ports GPIO_DIP_SW2]
[get_ports GPIO_DIP_SW1]
[get_ports GPIO_DIP_SW1]
[get_ports GPIO_DIP_SW0]
[get_ports GPIO_DIP_SW0]
[get_ports GPIO_SW_N]
[get_ports GPIO_SW_S]
[get_ports GPIO_SW_S]
[get_ports GPIO_SW_W]
[get_ports GPIO_SW_W]
[get_ports GPIO_SW_C]
[get_ports GPIO_SW_C]
[get_ports GPIO_SW_E]
[get_ports GPIO_SW_E]
[get_ports CPU_RESET]
[get_ports ROTARY_PUSH]
[get_ports ROTARY_INCA]
[get_ports ROTARY_INCB]
