SYSTEM SPECIFICATIONS:

Sediment Prefilter
Carbon Filter
RO Membrane Type
DI Cartridges
Rejection Rate
Input Water Pressure
Input Water Temp
Recovery Rate
Nominal Membrane Flow Rates @ 60 psi, 77° F:
GPD (lpd)
90 (340)
180 (680)
Higher TDS, harder tap water, higher temperature, greater recovery rate, or
lower operating pressure may contribute to reduced permeate flow and/or
lower TDS rejection.
Reverse Osmosis Membrane Feed Water Requirements
Operating Pressure*
pH Range
Maximum Temperature
Maximum Turbidity
Maximum Silt Density Index
Maximum Chlorine
Maximum TDS
Maximum Hardness
Maximum Iron
Maximum Manganese
Maximum Hydrogen Sulfide
Langelier Saturation Index
*Operating pressure less than 40 psi may require a booster pump:
Use BPLF-MO-115(-230) for Manual Operation, or
BPHF-PS-250/4-115 with Electronic Solenoid and Pressure Switch Control
*Operating pressure greater than 80 psi may require a pressure reducing valve.
SpectraPure
E-mail: sales@spectrapure.com Visit us on the web www.spectrapure.com
0.5 micron MicroTec™ sediment prefilter (SF-MT-0.5-10)
0.5 micron carbon block prefilter (CF-0.5-10)
Thin-Film Composite (TFC)
MaxCap DI
®
SilicaBuster™ DI
98% average
60 psi (4.15 bar) line pressure*
77°F (25°C)
20% (i.e. 20% of the water will be collected as pure water)
Product Water Flow Rate
235ml/min
470 ml/min
Inc .
®
Fax 480.894.6109 Fax us toll-free 1.877.527.7873
®
Concentrate Flow Rate
940 ml/min
1880 ml/min
40 – 80 psi (2.75 –5.5 bar)
3 –10
113° F (45° C)
1.0 NTU
5.0 (based on 15 min. test time)
less than 0.1 ppm
1500 ppm
10 grains (170 ppm as CaCO 3 )
less than 0.1 ppm
less than 0.1 ppm
0 ppm
LSI must be negative
:
