SYSTEM SPECIFICATIONS:

Sediment Prefilter
Carbon Filter
RO Membrane Type
DI Cartridges
Rejection Rate
Input Water Pressure
Input Water Temp
Recovery Rate
Dimensions:
MMC-RODI-90-10-MF
MMC-RODI-180-10-MF
Nominal Membrane Flow Rates @ 60 psi, 77° F, & 250 ppm TDS :
GPD Product Water Flow Rate
90 237 ml/min
180 473 ml/min
Permeate flow and TDS rejection is based on the following test conditions:
250 ppm softened tap water, 77° F (25° C), 33% recovery and 60 psi.
Higher TDS, harder tap water, lower water temperature, greater recovery rate, or lower
operating pressure may contribute to reduced permeate flow and/or lower TDS rejection.
Reverse Osmosis Operating Limits:
Operating Pressure*
pH Range
Maximum Temperature
Maximum Turbidity
Maximum Silt Density Index
Free Chlorine Tolerance
Maximum Iron
Maximum Manganese
Maximum Hydrogen Sulfide
*Operating pressure less than 40 psi may require a booster pump:
Operating pressure greater than 80 psi may require a pressure regulator.
SpectraPure
4
0.5 micron sediment prefilter (SF-MT-0.5-10)
0.5 micron carbon block prefilter (CF- 0.5 -10)
90 GPD SpectraSelectPlus™ TFC Membrane
(Use 2 for 180 GPD Systems)
Mega MaxCap™ Extended Life DI Cartridge (DI-MMC-10)
Enduro DI™ DI Finishing Cartridge (DI-MB-ENDI-10)
Typical stabilized conductivity rejection 99%
Minimum conductivity rejection 98%
60 psi (4.15 bar) line pressure*
77°F (25°C)
33% (i.e. 33% of the water will be collected as pure water)
Inc.
®
480.894.5437 Call us toll-free 1.800.685.2783
2167 East Fifth St, Tempe, Arizona 85281
®
21" W x 15" H x 7" D (One Membrane)
21" W x 15" H x 7" D (Two Membranes)
Concentrate Flow Rate (2:1)
473 ml/min
946 ml/min
40 – 80 psi (2.75 – 5.5 bar)
2 – 11
113° F (45° C)
1.0 NTU
5.0 (based on 15 min. test time)
less than 0.1 ppm
less than 0.1 ppm
less than 0.1 ppm
0 ppm
