SYSTEM SPECIFICATIONS

Sediment Pre-Filter 0.5 micron MicroTec™ sediment pre-filter
Carbon Filter 0.5 micron carbon block pre-filter
RO Membrane Type Thin-Film Composite (TFC)
DI Cartridges SilicaFree™ Color-Indicating Anion
Dual Layer Color-Indicating Deionizing
Rejection Rate Greater than 98% average
Input Water Pressure 60 psi (4.15 bar) line pressure*
Input Water Temp 77°F (25°C)
Recovery Rate 20% (i.e. 20% of the water will be
collected as pure water)
Nominal Membrane Flow Rates @ 60 psi & 77° F :
GPD (lpd) Product Water Flow Rate
25 (95) 66 ml/min
40 (151) 105ml/min
60 (228) 158 ml/min
90 (340) 235ml/min
180 (680) 470ml/min
Reverse Osmosis Membrane Feed Water Requirements
For the 1 year SpectraSelect TFC membrane pro-rated warranty to be honored, the
following conditions must be met:
Operating Pressure*
pH Range
Maximum Temperature
Maximum Turbidity
Maximum Silt Density Index
Maximum Chlorine
Maximum TDS
Maximum Hardness
Maximum Iron
Maximum Manganese
Maximum Hydrogen Sulfide
Langlier Saturation Index
*Operating pressure less than 40 psi will require a booster pump:
less than 49 GPD use BPLF-MO-115(-230),
more than 49 GPD use BPHF-MO-115(-230).
*Operating pressure greater than 80 psi will require a pressure reducing valve.
SpectraPure®Inc.
480.894.5437 Call us toll-free 1.800.685.2783
2167 East Fifth St, Tempe, Arizona 85281
6
®
Concentrate Flow Rate
264 ml/min
420 ml/min
632 ml/min
940 ml/min
1880 ml/min
40 – 80 psi (2.75 – 5.5 bar)
3 – 11
100° F (38° C)
1.0 NTU
5.0 (based on 15 min. test time)
less than 0.1 ppm
2000 ppm
10 grains (170 ppm as CaCO3)
less than 0.1 ppm
less than 0.1 ppm
0 ppm
LSI must be negative
SpectraPure
TESTING THE QUALITY OF THE MEMBRANE
Membrane Output Calculation
Membranes produce the rated gallons per day (GPD) at 60 psi (4.1 bars) operat-
ing pressure, 77°F (25°C) operating temperature and 500 ppm total dissolved
solids.
Membrane output gallons per day (GPD) depends on operating pressure, water
temperature and the ppm TDS in the feed water.
Expected GPD = Rated GPD × PCF × TCF
PCF is the pressure correction factor
TCF is the temperature correction factor
Calculation of Pressure Correction Factor (PCF):
the membrane is directly proportional to the applied pressure.
Note: The membrane is rated to produce the rated GPD at 60 psi. For any pres-
sure other than 60 psi the output GPD is multipled by the PCF.
PCF = Line Pressure (in psi) ÷ 60
Calculation of Temperature Correction Factor (TCF):
also decreases with decrease in temperature. This is because water viscosity
increases with decrease in water temperature.
Temperature Correction Factor Table (TCF)
°F /°C TCF °F \°C
41.0 /5 0.521 59.0 /15
42.8 /6 0.540 60.8 /16
44.6 /7 0.560 62.6 /17
46.4 /8 0.578 64.4 /18
48.2 /9 0.598 66.2 /19
50.0 /10 0.620 68.0 /20
51.8 /11 0.640 69.8 /21
53.6 /12 0.661 71.6 /22
55.4 /13 0.684 73.4 /23
57.2/14 0.707 75.2 /24
SpectraPure®Inc .
Fax 480.894.6109 Fax us toll-free 1.877.527.7873
E-mail: spectra@spectrapure.com Visit us on the web www.spectrapure.com
®
The output (GPD) from
The output (GPD)
TCF °F \°C TCF
0.730 77.0 /25 1.000
0.754 78.8 /26 1.031
0.779 80.6 /27 1.063
0.804 82.4 /28 1.094
0.830 84.2 /29 1.127
0.857 86.0 /30 1.161
0.884 87.8 /31 1.196
0.912 89.6 /32 1.232
0.941 91.4 /33 1.267
0.970 93.2 /34 1.304
