System Specifications - SpectraPure The Eliminator Operator's Manual

SpectraPure

SYSTEM SPECIFICATIONS:

Sediment Pre-Filter
Carbon Filter
RO Membrane Type
Rejection Rate
Input Water Pressure
Input Water Temp
Recovery Rate
Nominal Membrane Flow Rates @ 60 psi, 77° F, & 500 ppm TDS :
GPD Product Water Flow Rate
100 263 ml/min
200 526 ml/min
Reverse Osmosis Feed Water Requirements
For the 1 year TFC membrane pro-rated warranty to be honored, the following conditions
Operating Pressure*
pH Range
Maximum Temperature
Maximum Turbidity
Maximum Silt Density Index
Maximum Chlorine
Maximum TDS
Maximum Hardness
Maximum Iron
Maximum Manganese
Maximum Hydrogen Sulfide
Langlier Saturation Index
*Operating pressure less than 40 psi may require a booster pump:
For manual operation, use BPHF-MO-115 (-230).
For automatic operation, use BPHF-PS-250/4-115 (-230)
*Operating pressure greater than 80 psi will require a pressure regulator.
SpectraPure®Inc.
2167 East Fifth St, Tempe, Arizona 85281
6
®
1 micron MicroTec™ sediment pre-filter
1 micron carbon block pre-filter
Thin-Film Composite (TFC)
98% average
60 psi (4.15 bar) line pressure*
77°F (25°C)
25% (i.e. 25% of the water will be
collected as pure water)
must be met:
40 – 80 psi (2.75 – 5.5 bar)
3 – 11
100° F (38° C)
1.0 NTU
5.0 (based on 15 min. test time)
less than 0.1 ppm
1500 ppm
16 grains (272 ppm as CaCO3)
less than 0.1 ppm
less than 0.1 ppm
0 ppm
LSI must be negative
480.894.5437 Call us toll-free 1.800.685.2783
Concentrate Flow Rate
789 ml/min
1578 ml/min
