SYSTEM SPECIFICATIONS:

Sediment Pre-Filter
Carbon Filter
RO Membrane Type
DI Cartridges
Rejection Rate
Input Water Pressure
Input Water Temp
Recovery Rate
Nominal Membrane Flow Rates @ 60 psi & 77° F :
GPD (lpd) Product Water Flow Rate
90 (340)
180 (340)
Reverse Osmosis Membrane Feed Water Requirements
For the 1 year SpectraSelect TFC membrane pro-rated warranty to be honored, the
following conditions must be met:
Operating Pressure*
pH Range
Maximum Temperature
Maximum Turbidity
Maximum Silt Density Index
Maximum Chlorine
Maximum TDS
Maximum Hardness
Maximum Iron
Maximum Manganese
Maximum Hydrogen Sulfide
Langlier Saturation Index
*Operating pressure less than 40 psi may require a booster pump:
Use BPLF-MO-115(-230) for Manual Operation, or
BPHF-PS-250/4-115 with Electronic Solenoid and Pressure Switch Control
*Operating pressure greater than 80 psi will require a pressure reducing valve.
SpectraPure®Inc .
E-mail: spectra@spectrapure.com Visit us on the web www.spectrapure.com
®
0.5 micron MicroTec™ sediment pre-filter
0.5 micron carbon block pre-filter
Thin-Film Composite (TFC)
®
M C DI
AX AP
SilicaBuster™ DI
98% average
60 psi (4.15 bar) line pressure*
77°F (25°C)
20% (i.e. 20% of the water will be
collected as pure water)
235ml/min
470ml/min
40 – 80 psi (2.75 – 5.5 bar)
3 – 11
100° F (38° C)
1.0 NTU
5.0 (based on 15 min. test time)
less than 0.1 ppm
2000 ppm
10 grains (170 ppm as CaCO3)
less than 0.1 ppm
less than 0.1 ppm
0 ppm
LSI must be negative
Fax 480.894.6109 Fax us toll-free 1.877.527.7873
Concentrate Flow Rate
940 ml/min
1880ml/min
