5.4.1

Riser Card Support

The server board provides three riser card slots identified as: Riser Slot #1, Riser Slot #2, and Riser Slot #3.
Note: The riser card slots are specifically designed to support riser cards only. Attempting to install a
PCIe* add-in card directly into a riser card slot on the server board may damage the server board, the add-in
card, or both.
The PCIe* bus interface for each riser card slot is supported by each of the two installed processors. The
following tables provide the PCIe* bus routing for all supported risers cards.
Note: A dual processor configuration is required when using Riser Slot #2 and Riser Slot #3, as well as the
bottom add-in card slot for 2U riser cards installed in Riser Slot #1.
Riser Slot #1 – Riser Card Options
2U - 3-Slot Riser Card
iPN – A2UL8RISER2
Top PCIe* Slot
CPU #1 – Port 3C
(x8 elec, x16 mech)
Middle PCIe* Slot
CPU #1 – Port 3A
(x8 elec, x16 mech)
Bottom PCIe* Slot
CPU #2 – Port 1A
(x8 elec, x8 mech)
Riser Slot #2 – Riser Card Options
2U - 3-Slot Riser Card
iPN – A2UL8RISER2
Top PCIe* Slot
CPU #2 – Port 2C
(x8 elec, x16 mech)
Middle PCIe* Slot
CPU #2 – Port 2A
(x8 elec, x16 mech)
Bottom PCIe* Slot
CPU #2 – Port 3C
(x8 elec, x8 mech)
35
Relion 1900e/2900e Manual

Figure 12. On-board Add-in Card Support

Table 9. Riser Card #1 - PCIe* Root Port Mapping

2U - 2-Slot Riser Card
iPN – A2UL16RISER2
Top PCIe* Slot
CPU #1 – Port 3A
(x16 elec, x16 mech)
Bottom PCIe* Slot
CPU #2 – Port 1A
(x8 elec, x8 mech)

Table 10. Riser Card #2 - PCIe* Root Port Mapping

2U - 2-Slot Riser Card
iPN – A2UL16RISER2
Top PCIe* Slot
CPU #2 – Port 2A
(x16 elec, x16 mech)
Bottom PCIe* Slot
CPU #2 – Port 3C
(x8 elec, x8 mech)
1U - 1-Slot Riser Card
iPN – F1UL16RISER2
PCIe* Slot
CPU #1 – Port 3A
(x16 elec, x16 mech)
1U - 1-Slot Riser Card
iPN – F1UL16RISER2
Top PCIe* Slot
CPU #2 – Port 2A
(x16 elec, x16 mech)
Revision 1.3
