Table 48. System Status Led State Definitions - Penguin Computing Relion 1900e Technical Manual

Color State
Off System is
not
operating
Green Solid on
Green ~1 Hz
blink
109
Relion 1900e/2900e Manual

Table 48. System Status LED State Definitions

Criticality
Not ready System is powered off (AC and/or DC).
•
System is in EuP Lot6 Off Mode.
•
System is in S5 Soft-Off State.
•
Ok Indicates that the System is running (in S0 State) and its
status is 'Healthy'. The system is not exhibiting any errors. AC
power is present and BMC has booted and manageability
functionality is up and running.
After a BMC reset, and in conjuction with the Chassis ID solid
ON, the BMC is booting Linux*. Control has been passed
from BMC uBoot to BMC Linux* itself. It will be in this state
for ~10-~20 seconds
Degraded - System degraded:
system is
• Redundancy loss such as power-supply or fan. Applies
operating in a
only if the associated platform sub-system has
degraded state redundancy capabilities.
although still
• Fan warning or failure when the number of fully
functional, or operational fans is less than minimum number needed to
system is
cool the system.
operating in
• Non-critical threshold crossed – Temperature (including
a redundant HSBP temp), voltage, input power to power supply,
state but with output current for main power rail from power supply
an impending and Processor Thermal Control (Therm Ctrl) sensors.
failure warning
• Power supply predictive failure occurred while redundant
power supply configuration was present.
• Unable to use all of the installed memory (more than 1
DIMM installed).
• Correctable Errors over a threshold and migrating to a
spare DIMM (memory sparing). This indicates that the
system no longer has spared DIMMs (a redundancy lost
condition). Corresponding DIMM LED lit.
• In mirrored configuration, when memory mirroring takes
place and system loses memory redundancy.
• Battery failure.
• BMC executing in uBoot. (Indicated by Chassis ID blinking
at 3Hz). System in degraded state (no manageability).
BMC uBoot is running but has not transferred control to
BMC Linux*. Server will be in this state 6-8 seconds after
BMC reset while it pulls the Linux* image into flash.
• BMC Watchdog has reset the BMC.
Power Unit sensor offset for configuration error is
•
asserted.
HDD HSC is off-line or degraded.
•
Description
Revision 1.3
