Feature
On-board storage
controllers and options
Security
Server Management
Power Supply Options
Storage Options
Supported Rack Mount
Kit Accessory Options
Refer to the Technical Product Specification for each Intel
information.
Revision 1.3
Relion 1900e/2900e Manual
• 10 x SATA 6Gbps ports (6Gb/s, 3 Gb/s and 1.5Gb/s transfer rates are supported)
• Two single port SATA connectors capable of supporting up to 6 Gb/sec
• Two 4-port mini-SAS HD (SFF-8643) connectors capable of supporting up to 6 Gb/sec /SATA
• One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
• Optional SAS IOC/ROC support via on-board Intel® Integrated RAID module connector
• Embedded Software SATA RAID
Intel ® Rapid Storage RAID Technology (RSTe) 4.0
o
Intel ® Embedded Server RAID Technology 2 (ESRT2) with optional RAID 5 key support
o
• Intel Trusted Platform Module (TPM) - AXXTPME5 (v1.2), AXXTPME6 (v2.0) and AXXTPME7 (v2.0)
®
(Accessory Option)
• Integrated Baseboard Management Controller, IPMI 2.0 compliant
• Support for Intel ® Server Management Software
• On-board RJ45 management port
• Advanced Server Management via an Intel
The server system can have up to two power supply modules installed, providing support for the
following power configurations: 1+0, 1+1 Redundant Power, and 2+0 Combined Power
Three power supply options:
• AC 750W Platinum
• DC 750W Gold
• AC 1100W Platinum
12Gb/sec Hot Swap Backplane Options:
• 8 x 2.5" SATA/SAS
• 8 x 2.5" Combo Backplane - SATA/SAS + up to 4 x PCIe NVM Express* (Not Hot Swappable)
• 8 x 2.5" Dual Port SATA/SAS
• 8 x 3.5" SATA/SAS
• 12 x 3.5" SATA/SAS
12 Gb/sec 24 port SAS Expander Support (Accessory Options)
• Internal mount
• PCIe* add-in
Storage Bay Options:
• 8 x 3.5" SATA/SAS Hot Swap Drive Bays + Optical Drive support + front panel I/O
• 12 x 3.5" SATA/SAS Hot Swap Drive Bays (Storage model)
• 8 x 2.5" SATA/SAS Hot Swap Drive Bays + Optical Drive support + front panel I/O
• 16 x 2.5" SATA/SAS Hot Swap Drive Bays + Optical Drive support + front panel I/O
• 24 x 2.5" SATA/SAS Hot Swap Drive Bays (Storage model)
• 2 x 2.5" SATA SSD Back of Chassis Hot Swap Drive Bays (Accessory Option)
• 2 x internal fixed mount 2.5" SSDs ( All SKUs)
• AXXPRAIL – Tool-less rack mount rail kit – 800mm max travel length
• AXXELVRAIL – Enhanced value rack mount rail kit - 424mm max travel length
• AXX1U2UCMA – Cable Management Arm – (*supported with AXXPRAIL only)
• AXX2POSTBRCKT – 2-post fixed mount bracket kit (not supported with 12 and 24 drive storage
SKUs)
Description
® Remote Management Module 4 Lite (Accessory Option)
Server System product family for more
®
