10. On-board Connector/Header Overview

This section identifies the location and pin-out for on-board connectors and headers of the server board that
provide an interface to system options/features, on-board platform management, or other user accessible
options/features.

10.1 Power Connectors

The server board includes several power connectors that are used to provide DC power to various devices.
10.1.1

Main Power

Main server board power is supplied from two slot connectors, which allow for one or two (redundant) power
supplies to dock directly to the server board. Each connector is labeled as "MAIN PWR 1" or "MAIN PWR 2"
on the server board. The server board provides no option to support power supplies with cable harnesses.
In a redundant power supply configuration, a failed power supply module is hot-swappable. The following
tables provide the pin-out for both "MAIN PWR 1" and "MAIN PWR 2" connectors.
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
GROUND
P12V
P12V
P12V
P12V
P12V
P12V
P12V
P12V
P12V
P3V3_AUX: PD_PS1_FRU_A0
P3V3_AUX: PD_PS1_FRU_A1
P12V_STBY
FM_PS_CR1
P12V_SHARE
TP_1_B24
FM_PS_COMPATIBILITY_BUS
91
Relion 1900e/2900e Manual

Table 26. Main Power (Slot 1) Connector Pin-out ("MAIN PWR 1")

Signal Name Pin # Pin# Signal Name
B1 A1 GROUND
B2 A2 GROUND
B3 A3 GROUND
B4 A4 GROUND
B5 A5 GROUND
B6 A6 GROUND
B7 A7 GROUND
B8 A8 GROUND
B9 A9 GROUND
B10 A10 P12V
B11 A11 P12V
B12 A12 P12V
B13 A13 P12V
B14 A14 P12V
B15 A15 P12V
B16 A16 P12V
B17 A17 P12V
B18 A18 P12V
B19 A19 SMB_PMBUS_DATA_R
B20 A20 SMB_PMBUS_CLK_R
B21 A21
FM_PS_EN_PSU_N
B22 A22 IRQ_SML1_PMBUS_ALERTR2_N
B23 A23 ISENSE_P12V_SENSE_RTN
B24 A24 ISENSE_P12V_SENSE
B25 A25 PWRGD_PS_PWROK
