Table 68. Relion 2900E Feature Set - Penguin Computing Relion 1900e Technical Manual

Feature
Chassis Type
Server Board Options
Processor Support
Memory
Chipset
Revision 1.3
Relion 1900e/2900e Manual
Figure 37. Relion 2900e
Table 68. Relion 2900e Product Family Feature Set
2U Rack Mount Chassis
• Relion 2900e w/Dual 1GbE ports – S2600WT2R
• Relion 2900e w/Dual 10GbE ports – S2600WTTR
• Two LGA2011-3 (Socket R3) processor sockets
• Support for one or two Intel
• Maximum supported Thermal Design Power (TDP) of up to 145 W.
• 24 DIMM slots – 3 DIMMs/Channel – 4 memory channels per processor
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates:
DDR4 RDIMM: 1600 MT/s (3DPC), 1866 MT/s (2DPC) and 2133 MT/s (1DPC)
o
DDR4 LRDIMM: 1600 MT/s (3DPC), 2133 MT/s (2DPC & 1DPC)
o
• DDR4 standard I/O voltage of 1.2V
Intel ® C612 chipset
Relion 2900e
Description
Xeon processors E5-2600 v3, v4 product family
® ®
152
