The GUI presented by the embedded web server authenticates the user before allowing a web session to be
initiated. It presents all functions to all users but grays out those functions that the user does not have
privilege to execute. For example, if a user does not have privilege to power control, then the item shall be
displayed in greyed out font in that user's UI display. The web GUI also provides a launch point for some of
the advanced features, such as KVM and media redirection. These features are grayed out in the GUI unless
the system has been updated to support these advanced features. The embedded web server only displays
US English or Chinese language output.
Additional features supported by the web GUI include:
•
Present all the Basic features to the users
Power on/Power off/reset the server and view current power state
•
•
Display BIOS, BMC, ME and SDR version information
•
Display overall system health.
Configuration of various IPMI over LAN parameters for both IPV4 and IPV6
•
•
Configuration of alerting (SNMP and SMTP)
Display system asset information for the product, board, and chassis.
•
Display BMC-owned sensors (name, status, current reading, enabled thresholds), including color-
•
code status of sensors.
Provide ability to filter sensors based on sensor type (Voltage, Temperature, Fan and Power
•
supply related)
Automatic refresh of sensor data with a configurable refresh rate
•
•
Online help
Display/clear SEL (display is in easily understandable human readable format)
•
•
Support major industry-standard browsers (Microsoft Internet Explorer* and Mozilla Firefox*)
The GUI session automatically times out after a user-configurable inactivity period. By default, this
•
inactivity period is 30 minutes.
Embedded Platform Debug feature - Allow the user to initiate a "debug dump" to a file that can be
•
sent to Intel
Virtual Front Panel. The Virtual Front Panel provides the same functionality as the local front
•
panel. The displayed LEDs match the current state of the local panel LEDs. The displayed buttons
(for example, power button) can be used in the same manner as the local buttons.
•
Display of ME sensor data. Only sensors that have associated SDRs loaded will be displayed.
•
Ability to save the SEL to a file
Ability to force HTTPS connectivity for greater security. This is provided through a configuration
•
option in the UI.
•
Display of processor and memory information that is available over IPMI over LAN.
Ability to get and set Node Manager (NM) power policies
•
•
Display of power consumed by the server
Ability to view and configure VLAN settings
•
Warn user the reconfiguration of IP address will cause disconnect.
•
•
Capability to block logins for a period of time after several consecutive failed login attempts. The
lock-out period and the number of failed logins that initiates the lock-out period are configurable
by the user.
Revision 1.0
Relion 1900e/2900e Manual
®
for debug purposes.
86
