Group 9 - Setting programs
Adjustable parameters
Various tests
Para-
Designation
meter /
group
9 01
Test output 0
9 02
Test output 1
9 0
Test output 2
9 04
Test output
9 05
Test output 4
9 06
Test input 0
9 07
Test input 1
9 08
Test input 2
9 09
Test input
9 10
Test input 4
9 11
Test input 5
9 12
Test input 6
9 1
Test input 7
9 14
Test input 8
4.24
4. Programmes
Range
Step
Factory
setting
01
00/01
01
00/01
01
00/01
01
00/01
01
00/01
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
00 - 01
0/1
0/1
Comments
01 = Heat on in  seconds
01 = Drum left active in  seconds
01 = External signal active in  seconds
01 = Fan active in  seconds
01 = Drum right active in  seconds
Control of door switch 0 = Open, 1 = closed
Control of vacuum switch 0 = Open, 1 = closed
Control of external switch 0 = Open, 1 = closed
Control of condensation filter switch 0 = Open, 1 = closed
Control of filter door switch 0 = Open, 1 = closed
Control of overheating 0 = OK, 1 = Error
Control of gas error inlet 0 = OK, 1 = Error
Control of motor 1 overheating 0 = OK, 1 = Error
Control of motor 2 overheating 0 = OK, 1 = Error
