The usage of the connections
It is possible to connect following features to the PCB.
P1
Motor control
P2
Vacuum and fan input
P3
Power on
P4
Power out
P5
Heat control
P6
Els-Network
P7
Els-Network
P8
18V AC out
P9
18v AC in
P10
RMC
P11
RS 232 - internal use (incl. 24V DC)
P12
RS 232 - programme
P13
Data bus (incl. 24V DC)
P14
Data bus (incl. 24V DC)
P15
Gas control
P16
Rotary (compass control)
P17
Display (compass control)
P18
Temperatur sensor and filter input
P19
Extern gas reset and service switch
P20
Discount and external error (option)
P21
Free dry
P22
CP, CMS, CMSNCB, ESS, PCR
P23
CMD
.8
