- Page 1 Operating manual T4300S Selecta Control 487 05 45 31/EN 08.38...
-
Page 3: Safety Precautions
Safety Precautions Safety Precautions Do not dry unwashed items in the machine The machine is not to be used if industrial chemicals have been used for cleaning. Do not allow minors to use the machine. Do not hose down the machine with water. The machine's door lock must under no circumstances be bypassed. -
Page 5: Table Of Contents
Operating manual Contents Glossary ..........6 Diagram of tumble dryer . -
Page 6: Glossary
Operating manual Glossary Auto Stop The tumble dryer stops automatically when the clothes are dry. AHL (Apartment House Laundry) Example: Communal laundries / Housing block laundries. OPL (On Premises Laundry) Example: Institutional laundries. RMC (Residual Moisture Control) The tumble dryer has residual moisture control. -
Page 7: Diagram Of Tumble Dryer
Operating manual Diagram of tumble dryer Upper drum door Upper drum operating panel Upper drum Upper drum lint drawer coin insert and coin drawer Bottom drum operating panel Instruction sign Bottom drum coin insert and coin drawer Bottom drum door Bottom drum lint drawer... -
Page 8: Instruction Signs/Operating Panels
Operating manual Instruction signs/operating panels Coin-operated laundries SELECTA CO N TRO L SELECTA CO N TRO L 487 09 10 01.00 487 09 10 01.00 487 09 11 06.00 OPL - Dryer with manual operation SELECTA CO N TRO L SELECTA CO N TRO L 487 09 11 05.00 AHL - Dryer with manual operation... -
Page 9: Operating Panels - Buttons And Symbols
Operating manual Operating panel - buttons and symbols P button Reversing Program selection button. Reversing on/off. Not active on pay machines. OPL laundries only. With RMC: Push button during operation, display shows: the residual moisture in the clothes. Cool-down time Time button Setting of cool-down time. -
Page 10: Programmes - Coin-Operated Laundries
Operating manual Programmes - Coin-operated laundries Temperature High Non-iron/normal wash Cotton and mixed fabrics Medium Non-iron/normal wash Cotton and mixed fabrics Fine wash/mild wash Delicate fabrics, No heat Airing bedspreads, duvets and bedclothes Load Full loads are recommended in order to achieve the best result. Full load is indicated in kilos of dry textile. -
Page 11: Coin-Operation
Operating manual Coin-operation Fill garments into the drum. Close the door Select temperature High Medium No heat Pay with coins / card Press start Wait for the dryer to stop or press stop. To prevent If the dryer is not emptied wrinkling: immediately after the drying time has Empty the dryer as... -
Page 12: Programmes - Opl
Operating manual Programmes - OPL Programmes P 01 - P 09 on dryers with RMC Program Process Textiles P 01 Extra dry Denim P 02 Ready to put away 100% cotton / poly cotton mixture / terry P 03 Ironing dry (5% moisture) Polyester / nylon P 04 Ironing dry (10% moisture) Wool / silk... -
Page 13: Tumble Dryer With Manual Operation - Opl
Operating manual Tumble dryer with manual operation - OPL Clean filter Fill garments into the drum Close the door P 01 Extra dry Select programme P 02 Ready to put away P 03 Ironing dry (5% moisture) P 04 Ironing dry (10% moisture) P 05 Ironing dry (15% moisture) set the drying... -
Page 14: Programmes - Ahl
Operating manual Programmes - AHL Programmes P 01 - P 02 Program Process Textiles P 01 Extra dry Denim P 02 Ready to put away 100% cotton / poly cotton mixture / terry Programmes P 01 - P 03 on dryers with RMC Program Process Textiles... -
Page 15: Tumble Dryer With Manual Operation - Ahl
Operating manual Tumble dryer with manual operation - AHL Clean filter Fill garments into the drum Close the door Select programme P 01 Extra dry P 02 Ready to put away P 03 Ironing dry (15% moisture) set the drying time Select temperature High... -
Page 16: Error Codes
Operating manual Error codes The tumble dryer has automatic error indication. Error indication is displayed as a flashing code. Please refer to the manual Selecta Control from ver. 4.xx for an explanation of error codes. A service technician must be contacted should an error be displayed. The user can, however, try to correct some error codes himself. -
Page 17: Maintenance
Operating manual Maintenance The following should be carried out at regular intervals, depending on machine usage. Daily • Check that the drum stops when either the loading door or the lint drawer is opened. If the dryer operates with the loading door or lint drawer open, the machine must be placed out of order until repairs are made. - Page 18 Operating manual Maintenance Quarterly Check that the following are not clogged by lint and dust or otherwise blocked: • The area surrounding the dryer • Exhaust duct • Fresh-air intake to the room Check that the exhaust system connections are tight. Quarterly, dryer with RMC Wipe off/clean drum and lifters with citric acid (Acidum citricum).
- Page 21 Skrotning av maskin När maskinen inte längre skall användas måste den lämnas till en återvinningsstation för destruktion. Många detaljer i maskinen går att återanvända, men den innehåller även annat material som måste tas om hand på ett korrekt sätt. Lämna därför aldrig maskinen eller delar av maskinen i hushållsavfallet, eftersom det kan leda till hälsorisker eller skador på...
- Page 23 HYDRO-EXTRACTORS N4..E. , N4..G2. , N4..S. Product standard: EN 60335 Försäkran om överensstämmelse EG-Conformiteitsverklaring Electrolux Laundry Systems Sweden AB Wij, Electrolux Laundry Systems Sweden AB SE-341 80 Ljungby, Zweden SE-341 80 Ljungby, Sverige försäkrar under eget ansvar att denna produkt, med typbeteckning och enl. ovan, verklaren hierbij op eigen verantwoordelijkheid dat het produkt van het type en met är tillverkad i överensstämmelse med följande direktiv:...
- Page 24 Share more of our thinking at www.electrolux.com ASP Buenos Aires SRL - Valentin Gomez 3154 - C.A.B.A.- Tel. / Fax. 011 - 4866 -5100 E mail asp@sion.com - www.aspbuenosaires.com.ar...
