Main Menu

Navigating the Main Menu

• To enter the main menu press the MENU button.
• To advance to the next menu press the MENU button again.

Exiting the Main Menu

• To exit the menu at any time press and hold the MENU button for 1.5 seconds.
Or
• Cycle through the menu items.
Frequency Display and Select
CH A 567.4
Single Receiver Mode
The Frequency Select menu is where the QRX receive frequency is set. This frequency needs to match the
transmitter's frequency.
To adjust the frequency
Press the INC key and DEC key to adjust the frequency.
•
In dual receive mode pressing the A/B key will toggle between the A and B frequency.
•
The > will indicate the frequency being adjusted.
•

Transmitter Gain Adjust

This menu is only available when Transmitter Remote Control is set to "ON" in the Extended Menu.
TX GAIN
Single Receiver Mode
From this page you will have the ability to remotely change the gain of the corresponding TRX transmitter
with ZaxNet if you have the QIFB option installed.
The transmitter gain menu will display the audio levels for the transmitter with marks at the -20dBFS and
0dBFS.
To adjust the gain
Press the INC key to raise the transmitters gain. As you increased the gain will see "+ + +" on the QRX.
•
Press the DEC key to lower the transmitters gain. As you decrease the gain you will see "- - -" on the
•
QRX.
In dual mode pressing the A/B key will allow you to toggle between the two transmitters.
•
CH A> 567.4
CH B 570.0
Dual Receiver Mode
TXA
GAIN
Dual Receiver Mode
9
