IFB Option Menu

Only available if the QIFB option board is installed

Navigating the IFB Option Menu

• Press and hold the DEC key when in the home screen to display the extended menu.
• Press the DEC key to advance to the IFB option menu.
• Press the MENU key to enter into the IFB option menu
(When in the IFB option menu the screen will display a black background with white letters)
• To advance to the next menu press the MENU key again.
• Press and hold the MENU key at any point to return to the top of the IFB option menu.

Exiting the Main Menu

• To exit the IFB Option Menu press the POWER key briefly.

IFB Home Screen

IFB HOME MENU
VER 1.56 TX 2.404
IFB Software IFB Mode ZaxNet
Version

IFB Status / TRX Transport Control

2.404
This menu displays the following information:
ZaxNet IFB frequency.
•
If the IFB is set to transmit or receive.
•
The transport commands being sent to the TRX transmitter.
•
IFB Audio Level Meter
•
Pressing the INC or DEC key will scroll through the commands.
REC -TRX is being told to record.
•
STOP - TRX is being told to stop.
•
PLAY - TRX is being told to play.
•
- - - - - No ZaxNet commands are being sent (Normal).
•
NOTE: Any changes to the transmitter transport status will affect ALL the transmitters with the
same group number
NOTE: When the IFB is set to Receive (RX) mode, the INC and DEC keys will not function and no
transport commands will be sent to the TRX.
TX or RX Frequency
TX STOP
