IFB Extended Menu

Navigating the IFB Extended Menu

From the IFB option home screen press and hold the DEC key to display the IFB extended menu.
•
Press the MENU key to get into the IFB extended menu
•
To advance to the next menu press the MENU key again.
•
Press and hold the MENU key at any point takes you to the top of the IFB extended menu.
•

Exiting the Main Menu

To exit the IFB Option Menu at any time press the POWER key briefly.
•

Input Trim Set

INPUT TRIM 0dB
This menu adjusts the input level from the 3.5mm IFB audio in connector.
This menu only works when the QIFB is in transmit mode.
• Range is from 12dB to -20dB in 1 dB increments.

Output Trim Set

OUTPUT TRIM 0dB
When the QIFB is in receive mode you can output the received IFB audio via 3.5 mm IFB connector. This
menu adjusts the audio output level. This menu only works when the QIFB is in receive mode.
Range is from 6dB to -20dB in 1 dB increments.
•

IFB Frequency Set

IFB TXCH: 2.404
(TX MODE)
Transmit Mode
IFB RXCH: 2.404
SIGNAL: 23
This menu adjusts the ZaxNet transmit and receive frequency of the QRX. Depending what mode the
IFB is set to (transmit or receive) will determine if the transmit or receive frequency will be displayed
for adjustment.
NOTE: Even number frequencies are recommended for better performance.
Receive Mode
Transmit Frequency
Receive Frequency`
Signal Strength
21
