Zaxcom QRX 235

Analog Output Routing

This menu is only available when the QRX is set to single receive mode.
OUTPUT ROUTING:
C1 = L C2 = R
OUTPUT ROUTING:
C1 = L R
This menu sets the analog output assignments when you are using the QRX in single mode.

QRX Software Update

PRESS
UPDATE SOFTWARE
This menu is where you update the QRX software from.
When in this menu pressing the INC key will start the update process.
After the INC key is pressed the QRX will wait and search for software that will be transmitted from a
TRX transmitter. After the QRX receives the program from a TRX transmitter the QRX will automatically
begin updating the software.
If the QRX is set to dual receive mode the QRX will display "CHANGE MODE TO UPDATE SOFTWARE."
If you see this you will need to set the QRX to single mode before you can update the software.
The LEFT output will be on TA5
connector 1 and the RIGHT output
will be on TA5 connector 2
Both the LEFT and RIGHT
outputs will be on TA5
connector 1 and connector 2
ll
TO
b d
15
Extended Menu
