Zaxcom QRX 235

IFB Output Mix

IFB OUTPUT MIX:
CH 1234
This menu selects which internal QRX audio channels received from the UHF signal will be broadcast via
ZaxNet by the IFB audio transmitter. You can select any combination of the 4 receive channels. What is
selected here will be broadcast when you select "QRX" in the IFB Input mix menu in the IFB option
menu. This setting is only for broadcasting the audio received from the UHF signal - not the audio
inputted via the IFB in.

QIFB Enable

IFB ENABLE:
YES
This menu switches the QRX IFB board ON / OFF if the QIFB board is installed.
Transmitter Remote Control Enable
TX REMOTE CTRL:
OFF
Transmitter remote control turns on the ability to remote control the corresponding TRX transmitter.
When set to ON you will have the ability to remotely change the gain, output power level, frequency
and transport commands of the TRX's recorder of the TRX transmitters with ZaxNet.

Time Code Jam Source

USE TIME CODE
FROM TRX900:
This menu selects the source of external time code the QRX will use.
• OFF - The QRX will use and output time code received via ZaxNet.
• ON - The QRX will use and output the time code received from the TRX transmitter. The time code is
embedded the UHF signal. This will be helpful if you were sending audio and time code to a camera
from the Zaxcom TRX900CL camera link.
14
Extended Menu
