Zaxcom QRX 235
Settings:
• 0: POWER=ON – Normal operation - the TRX will be fully powered ON
• 1: POWER=ON – Normal operation (same as 0) filler to prevent accidental power setting adjustment.
• 2: POWER=ON – Normal operation (same as 0) filler to prevent accidental power setting adjustment.
• 3: POWER=ON – Normal operation (same as 0) filler to prevent accidental power setting adjustment.
• 4: POWER=ON – Normal operation (same as 0) filler to prevent accidental power setting adjustment.
• 5: POWER=WAKE – You would select this to wake a TRX transmitter to full power when the Boot Up
Mode is set to Remote Standby.
• 6: POWER=LOW2 – This setting can put the TRX transmitter into and out of a low power setting.
You can come in and out of LOW 2 mode as needed. When you are in LOW 2 mode "LOW 2" will be
displayed on the TRX's home screen. Note LOW 2 will not disable recording but it will be muted.
Once you have reduced the TRX power to Low 2 you can power down your QRX. Once you power up
the QRX all TRX's being controlled will automatically come up to full power since after a power cycle
the QRX will boot up to the 0 Power setting.
NOTE: If the TRX is not in range of the ZaxNet signal, the power setting command will have to be
repeated once the transmitter comes back into range.

Time Code Set

TC TIME ENTRY:
>H00
This menu is where you can set the QRX's internal time code generator. This would be necessary if you
are not receiving time code from another source and need to feed time code to the transmitter.
The > indicates the item that will be adjusted. To advance to the next field, press the A/B key on the
front panel.
H (Hours) use the INC or DEC key to adjust the hours.
•
M (Minutes) use the INC or DEC key to adjust the minutes.
•
JAM - Use the INC key to JAM QRX's TC Generator with the entered time.
•
The seconds and frames fields are automatically entered as zero (0).

Time Code Frame-Rate Select

TIMECODE 23.98
GEN: 01:02:34:02
This menu sets the frame-rate of the QIFB time code reader / generator.
The QRX supports all standard time code frame rates: 23.98, 24, 25, 29.97DF, 29.97DF, 30 DF, 30 NDF
M00 JAM
20
IFB Menu
