Zaxcom QRX 235

Blue LED Meter Mode

LED METER
MODE:
This menu sets the action of the bottom LED in each group (total of 4 groups).
The side mount LEDs were designed to give you a visual confirmation that audio is being received at the
QRX. This menu gives you the option to display that a valid RF signal is getting to the QRX even if no
audio is being sent.
• OFF - The bottom LED will only display the audio modulation and the blue LED is disabled.
• BLUE FULL TIME - Turns the bottom LED blue for each channel that is receiving a valid RF signal. When
the audio has gotten to the point of displaying a level for that channel, the bottom LED will continue
to show blue but with a tint of the appropriate modulation color of that channel's LEDs.
• BLUE PART TIME - Turns the bottom LED blue for each channel that is receiving a valid RF signal. Once
the audio level has gotten to the point of displaying a level for that channel, the blue color is replaced
with the appropriate modulation color of that channels LEDs.

Encryption Code Set

ID1: 000 ID0: 000
This menu sets the encryption code on the QRX. This code needs to match the encryption code of the
associated transmitters.
If you set an encryption code on the transmitter the transmitted audio will be encrypted and can
only be listened to if the QRX has the same matching encryption code entered. When the codes do
not match, all that will be heard is white-noise.
These two sets of numbers are formed into a single six-digit encryption code which provides a total
of 16,777,216 possible combinations.
To adjust the encryption code
Press the A/B key to advance to the next character.
1.
To change the designated character, press the INC or DEC key.
2.
To exit this page, press and hold the MENU key.
3.
NOTE: Both of these codes should always be set to 000 for normal un-encrypted operation.
17
Extended Menu
