Zaxcom QRX235

Specifications

Receiver
Receiver Type:
RF Modulation:
RF Frequency Range:
RF Frequency Step:
RF Bandwidth: US Mode:
European Mode:
Channel Separation:
Sensitivity:
Antenna Connector:
Receiver Audio - Analog Outputs
Channels:
Audio Level:
Dynamic Range:
Distortion:
DAC Bit-depth:
DAC Rate:
Connector (x 2):
Receiver Audio - Digital Outputs
Channels:
Sample-rate:
AES Reference:
Connector:
Serial Control
Protocol:
Connector (x 2):
IFB Transmitter/Receiver (optional)
Transmitter
RF Power Output:
Emission Designator:
FCC Part:
Receiver Sensitivity:
Frequency Response:
RF Modulation:
RF Frequency Range:
RF Frequency Step:
RF Bandwidth:
Channel Separation:
Antenna Connector:
True / antenna diversity (mono or stereo)
Proprietary digital method
518.0 to 692.0 MHz
100 KHz
200 KHz
125 KHz
500 KHz (700 KHz recommended)
-110 dBm
50-ohm SMA female
Up to 4
Line Level 0 dBu active balanced
114 dB
0.001%
24 bit
48 kHz
TA-5M
Up to 4
32 kHz
Wordclock and AES reference
TA-5M
RS-422, RS-485
USB
50 mW
180 KV2E
CFR Title 47, Part 18
-96 dBm
20 Hz to 12 kHz
Digital Spread Spectrum
2.403 to 2.475 GHz
0.001 GHz (1 MHz)
1 MHz
2 MHz
50-ohm SMA female
36
