Zaxcom QRX235
IFB Audio
ADC Bit-depth:
ADC Rate:
Dynamic range:
Distortion:
Frequency Response:
System Group Delay:
IFB Audio Input/Output
Connector:
Type:
Level:
Impedance:
Time code Input/Output (common connector)
Input
Level Range:
Output
Level Range:
Connector:
Type:
Impedance:
Time code Reader/Generator
Clock Accuracy:
Time code Type:
Time code Frame-rates:
Physical
Weight:
Dimensions
External Power:
Internal Power:
Display:
24 bit
48 kHz
103 dB
0.01%
20 Hz to 12 kHz
10 ms
1/8" Stereo (3.5 mm)
Unbalanced
-10 to +8 dBu
10k ohms
1 to 5V, P-P
.2 to 3V, P-P
1/8" Stereo (3.5 mm) Stereo
Unbalanced
10 k ohms
1.54 PPM (1 frame out in 6 hours)
SMPTE
23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF
6.0 oz. (170 grams)
(H x W x D): 1.25" x 3.25" x 5.25" (32mm x 83mm x 133mm)
9 to 18 VDC (270 mA @ 12 VDC – no side LEDs, 390 mA – w/ LEDs illuminated)
N/A
Graphic LCD panel
37
Specifications
