Updating the IFB Software

This menu is only available when the IFB MODE is set to is to (RX) Receive mode
PRESS UP 5X TO
UPDATE IFB SOFT
This allows you to update the QIFB software. See the firmware section of this manual for additional
information,

Time Code Output Level Set

TC OUTPUT LEVEL:
1.0V (DEFAULT)
This menu allows you to adjust the voltage level of the time code out of the 3.5mm time code
connector. This is useful for some cameras or time code devices that may need a different level time
code signal.

Time Code Frame Rate Set

TC FRAME RATE
23.98
This menu sets the time code frame-rate of the QRX internal time code generator.
The QRX supports all standard time code frame rates: 23.98, 24, 25, 29.97DF, 29.97DF, 30 DF, 30 NDF.

Time Code Jam Mode Set

TC JAM MODE:
AUTO-LOAD
This menu sets how the QRX jams time code and how it uses that time code.
MANUAL (OFF) -This setting allows you to enter your own time code.
•
AUTO-JAM - The QRX will continuously jams time code via ZaxNet or from the UHF signal from a
•
TRX transmitter - provided you have set "Uses TC from TRX900" to ON.
AUTO-LOAD - This is used when working with record-run time code. The TRX transmitter can start
•
and stop when it detects the record-run time code starting and stopping. The TRX transmitter
receives the record commands from the QRX IFB. If you are using the auto load feature on the TRX
transmitter this needs be set to auto load as well.
23
Extended Menu
