Time Code Delay Set

TC DELAY:
0 (NORMAL)
This menu allows you to adjust the delay of the time code out of the time code connector.
The QRX will allow you to either delay or advance the time code up to +/-50 frames in 0.5 frame
increments.

Time Code Mute Time Set

TCJAM MUTE TIME:
0MS (DEFAULT)
This menu allows you to adjust the length of time the time code is muted whenever a time code jump
is detected. If the time code changes the time code out of the QRX will be muted by the time set in this
menu. This menu was added to help the RED camera jam its time code properly. In the case of a Red
One you would want to set this to 1000MS

Audio Delay Set

AUDIO DELAY:
OFF
This menu is where the delay of the IFB audio that is broadcasted via ZaxNet. This is useful if you need
to delay the audio feed to match the video dely.
Adjustable range is from 5 to 400 MS in 5 MS increments.

ZaxNet Output Enable

ZAXNET OUTPUT:
OFF
This menu is where you toggle if the QRX will embed and output ZaxNet commands in the user bits of
its time code output. This should be set to OFF most of the time since most non Zaxcom devices cannot
decipher ZaxNet commands via time code.

IFB Transmit Power Level Set

This menu is only available when the IFB MODE is set to is to (TX) Transmit mode in the IFB Extended Menu
IFB TX POWER: 7
This menu is where the transmit power of the ZaxNet transmitter is set.
Power range is 0 through 7 with 7 being the highest
