VRX1 Specifications

IFB Receiver
Receiver type: Direct Conversion
RF Frequency Range: 192-217 MHz (76-86 MHz optional)
RF Sensitivity: .8uV for 20dB
Modulation (in Analog Mode): FM
Minimum Channel Spacing (in Analog mode): 100KHz
RF Frequency Channels: 10
Frequency steps (in Analog Mode): 25KHz
Spurious RF rejection: Greater than 90dB
Antenna: Headphone cable
Receiver Audio
System Delay: 4mS to 400mS adjustable (minimum 4mS of overall receiver latency in Analog FM mode)
Audio bandwidth: 16KHz
Audio Signal to Noise Ratio: 97dB (signal full quieting)
Analog FM Distortion: less than 1%
Output Connector: 1/8" Stereo (3.5 mm)
Minimum HP Impedance: 16 ohms
Audio output level: 2.8V max driving 16 ohms
Output type: Headphone or balanced differential
Physical
Weight: 4oz (including NiMh batteries)
Dimensions (H x W x D): 4.60"x2.46"x.640"
External Power: via USB, 700 mA while charging
Internal Power: NiMh batteries up to 13 hours (2450 mA hour battery)
