Time Code Output Enable

TIMECODE OUTPUT
OFF
The ERX can output time code through either side of the headphone jack. When sending time code to the
headphone jack, the time code will override the audio to that selected output. The ERX can be configured to
send audio only, time code only or time code and audio simultaneously. Adjusting the settings in this menu will
allow the ERX to act as an audio monitor, a time code device or both. The later allows for the ERX to be
mounted on a camera and feed the camera both audio and time code simultaneously. The output cable should
be wired to match the time code / audio routing set in this menu.
OFF - Time code output is disabled and only audio will be outputted from the headphone jack.
•
ON: OUT BOTH -Outputs only time code to both left and right out of the headphone jack.
•
ON: OUT RIGHT - Outputs time code to the right side and audio to the left side of the headphone jack.
•
ON: OUT LEFT - Outputs time code to the left side and audio to the right side of the headphone jack.
•

Time Code Delay Set

TC DELAY
0 (NORMAL)
The time code delay menu allows the time code out of the ERX to be advanced or delayed to create a time code
offset. The time code adjustments can be set from -50 frames to +50 frames in 0.5 frame increments.

Time Code Jam Mute

TCJAM MUTE TIME:
0MS (DEFAULT)
The time code mute time menu sets how long the time code output will be muted when the time code is being
jammed, or if the time code changes. When this is set to on, any value other than 0MS, the time code output
will mute for the duration selected whenever the ERX sees a jump in time code of 2 frames or more. This
simulates removing the time code completely from a device and plugging it back in so that the receiving device
recognizes that there is new time code. This was added to fix a bug in some older RED camera software
versions.
Adjustments can be set from 500MS to 2000MS in 500MS increments.
Please note that if using a Red camera the time code jam mute will likely need to be set to 1000 milliseconds.
