IFB Extended Menu

Navigating the IFB Extended Menu

From the IFB option home screen press the DEC key to enter the IFB extended menu.
•
Press the MENU key to advance to the next menu item.
•
Press and hold the MENU key at any point to jump to the top of the IFB extended menu.
•
To exit the IFB extended menu at any time press the POWER key briefly.
•

Input Trim Set

INPUT TRIM 0dB
When the QIFB is in transmit mode the audio inputted on the 3.5mm IFB connector can be broadcast over
ZaxNet. This menu adjusts the input level from the 3.5mm IFB audio in connector.
The adjustment range is from -20dB to 12dB in 1 dB increments.

Output Trim Set

OUTPUT TRIM 0dB
When the QIFB is in receive mode the audio received over ZaxNet can be outputted via the 3.5 mm connector.
This menu adjusts the audio output level on that connector.
The adjustment range is from -20dB to 6dB in 1 dB increments.

IFB Frequency Set

IFB TXCH: 2.404
(TX MODE)
Transmit Mode
IFB RXCH: 2.404
SIGNAL: 23
Receive Mode
The IFB frequency set menu is where the ZaxNet transmit and receive frequency of the QRX235 is set. Depending
what mode the IFB is set to (transmit or receive) will determine if the transmit or receive frequency will be
displayed for adjustment. Please note that even number frequencies are recommended for better performance.
Transmit Frequency
Receive Frequency
Signal Strength
