AES Output Enable

AES - 1 2: ON
AES - 3 4: OFF
The AES output menu enables the TA5 connectors to output an AES signal.
ON - Indicates that the TA5 will output AES audio.
•
OFF - Indicates that the TA5 will output analog audio.
•

Output Assignment

This menu is only available when the QRX is set to dual receive mode.
OUTPUTS:
NORMAL
The output assign menu sets what audio is outputted from each TA5 connector when the QRX is set to dual
mode receiving mono transmitters.
SPLIT / NORMAL - The signal from each transmitter will be outputted on individual TA5 connectors.
•
Transmitter 1 will be outputted on TA5 1 and transmitter 2 will be outputted on TA5 2.
COMBINED / SWAP - The signal from each transmitter will be combined on a single TA5 connector.
•

IFB Output Mix

IFB OUTPUT MIX:
CH 1 2 3 4
The IFB output mix selects which receive audio channels will be broadcast via ZaxNet when the QIFB option is
installed and set to transmit. Any combination of the 4 receive channels can be selected. The selected channels
will be broadcast when "QRX" is selected in the IFB input mix menu. Please note that this setting is only for
broadcasting the audio received from the UHF signal - not the audio inputted via the IFB in.

IFB Enable

IFB ENABLE:
YES
IFB enable turns on the QIFB option board - when installed. Please note that the IFB option board needs to be
enabled for the QRX235 to send or receive ZaxNet commands.
12
Extended Menu
