TX Series User's Manual
Adjusting the Pressure of the Printhead
As shown in Figure , there are two set of nuts and screws for adjusting the pressure of Printhead.
The procedures of adjusting the pressure of printhead
1. Unscrew the cap nut counterclockwise to loosen it, please mind that do not separate the nut from the screw;
2. Press down the cap nut, and then screw the collar nut to adjust the pressure for printhead; the pressure will be
increased when the nut screws counterclockwise (as shown in figure 3-5), whereas the pressure will be decreased
if it screws clockwise.
3. When the collar nut has been adjusted to the appropriate position, fasten the cap nut to lock the position。
4. Apply steps 1~3 on the other set of nuts and screw, then the pressure adjustment are completed.
Figure 3-5
Chapter 3: Operations and Settings
Cap nut
Collar nut
26
