TX Series User's Manual
1. Platen Roller
2. Printhead Module
3. Ribbon Supply Spindle
4. Ribbon Take-up Spindle
Note: Figure 2-2(b) shows the detailed structure of TX3 and TX6.
4
3
2
1
5. Media Roll Guide (out)
6. Bolt
7. External Media Loading
Opening
8. Media Spindle
Figure 2-2(b)
9.
10. Handle
11. Media Sensor Cover Plate
Chapter 2: Setup and Use
5
6
7
8
9
10
11
ESD Brush
6
