Loading Path

See figure 2-4(a) shows the loading path in TX2.
4
3
2
1
1. Media Sensor Handle 4. Ribbon Path
2. Media Path
3. Platen Roller
Figure 2-4(b) shows the loading path in TX3 and TX6.
4
3
2
1
1. Media Sensor Handle
2. Media Path
3. Platen Roller
Figure 2-4(a)
5. Ribbon Guide
6. Media Guide Lever
Figure 2-4(b)
4. Ribbon Path
5. Ribbon Guide
6. Media Guide Lever
Chapter 2: Setup and Use
5
6
7
7. Media Guide Slide
5
6
7
7. Media Guide Slide
