TX Series User's Manual

Loading the Ribbon

Note: Load ribbon only when using the thermal transfer printing method. Remove any ribbon that may be loaded
when using the direct thermal printing method.
To install the ribbon:
1. Lift to open the right cover of the printer.
2. Turn the Lever counter clockwise to release the Printhead Module.
Printhead Module
3. Stick a label to the outside/ inside of the ribbon to check which side the ink is on. See Figure 2-6.
Ribbon
Label
Figure 2-5
Figure 2-6
Chapter 2: Setup and Use
Lever
10
