S7000 Series TV Analyzer

6.1.3 General Settings

Select the GENERAL Tab to display and adjust the general system settings. The following settings are
included in the GENERAL Tab, as shown in Figure 2-3.
 Network Settings
PING

 Display and Battery Settings
 Date and Time Settings
Skin Settings

 Language Settings
 Operator Name
 Factory Reset
7. Network Settings
Users may access network with RJ45 connection.
 Automatic Network Parameters, refer to Figure 2-3.
To enable automatic network parameters sent from a DHCP server, perform the following steps:
keys ( UP / DOWN / LEFT / RIGHT ) to highlight the DHCP check box.
1) Select
key ( ENTER ) to select the check box.
2) Select
Once the DHCP check box is selected, the IP Address, Net Mask, Gateway, and DNS will all be
3)
assigned by the DHCP server and can not be manually adjusted.
Operation Manual
15
