65.1 Brief introduction

TS analyzer module supports DVB and ATSC standard TS analysis including RealTime TS and Offline
TS and also IPTV data. Subfunctions are as follows: RealTime Decoder, Recorder, Channel Edit,
Replay, Basic Information, TR101 290, PID Viewer, Program Information, PCR, Program List, PSI/SI,
Data Capture and TR101 290 Parameters Setting.
TS function user guide is provided in RF input case.
key ( TV ) to start the TS Meas function if the digital channel is selected, and the RealTime
Press the
subfunction is provided first as default, as Figure 5-1.

65.1.1 Application range

Digital TV installation and debugging: To analysis, test and diagnose.
Digital TV measurement: To measure.
Digital TV transmission detect: To detect.
Digital TV equipment development: To debug and develop the related equipment.

65.1.2 Standards

 MPEG-1
1) ISO-IEC-11172-2(Video)
2) ISO-IEC-11172-3(Audio)
 MPEG-2
1) ISO/IEC 13818-1 (System)
2) ISO/IEC 13818-2 (Video)
3) ISO/IEC 13818-3 (Audio)
4) ISO/IEC 13818-6 (DSM-CC)
5) ISO/IEC 13818-7 (AAC)
 MPEG-4
1) ISO/IEC 14496-2 (Video)
2) ISO/IEC 14496-3 (Audio)
 H264
1) ITU-T H.264
2) ISO/IEC 14496-10 (AVC)
