d. LNB power supply indicator. It indicates that the instrument runs LNB power when this icon appears
on the title bar. Please see Section 2: SETUP->INTF.->LNB POWER to get the operation.
e. GPS indicator. It indicates that the instrument recognize GPS module successfully when this icon
appears on the title bar.
f.
LAN connector indicator. It indicates that the instrument connects the LAN line successfully when
this icon appears on the title bar.
g. USB connector indicator. It indicates that the instrument recognizes USB successfully when this
icon appears on the title bar.
S7000 Series TV Analyzer
Operation
Manual
7
