3.1.4 Power Supply

S7000 is powered by both built-in battery and external power adapter. Please charge S7000 before
using.
4. Battery
S7000 TW use built-in 7.4V/13AH Li-Polymer battery and work over 5 hours when fully charged. Once
the voltage of the battery is lower than 7.15V, S7000 TW pops up a message box: LOW BATTERY!
Once the voltage of the battery is lower than 6.8V, S7000 TW pops up a message box: LOW BATTERY!
and the battery icon flashes. Once the voltage of the battery is lower than 6.5V, S7000 TW pops up a
message box: LOW BATTERY! and the buzzer bells. The instrument will shut down automatically after
the buzzer stops belling.
NOTE:1 The instrument can be only charged by the charger provided together
with S7000.
2 It is suggested to power off the instrument when charging.
3 Low temperature may reduce the capability of the battery, but the battery
will not be damaged; And high temperature will cause the unrecoverable
damage.
4 Please replace the battery when its working hours shorten distinctly.
5. Charge
Please charge the instrument as following charge process:
1) Insert the charge output plug to S7000 charge socket.
2) Connect the charger to AC 100V-240V Power and the charge light will light with red.
3) When the charge light becomes to green, the instrument has been charged the whole capacity. We
suggest you charge one more hours to extend battery life. After charging, you can disconnect the
charge input plug with power and pull out the charge output plug.
NOTE: The battery must use the relevant charger to charge. The instrument can
not be charged in the temperature beyond 10 ℃ ～ 35 ℃ , otherwise the
