1.2 Terminology

Telephone line
Line connection
Line disconnection
Option
Incoming call
Outbound call
Call connection
Code lock
Code relay
External code
Internal code
The manufacturer continuously improves the product firmware. The
technology used allows you to upload to Brave the latest version of the
firmware any time using a standard computer with BraveSet and USB
cable. The latest version of the firmware is available at
www.alphatechtechnologies.cz
Analogue (2 conductors) connecting to a public telephone
network (public line) or to a local telephone system (local
line).
The start of a telephone connection (the same as picking up a
phone handset).
End of connection (the same as replacing a phone handset).
DTMF - a tone option combination of two tones (chooses also
special signs * and #, uses breaking the loop Flash)
Impulsive – option by breaking the loop (chooses only digits)
Connection between a Brave and a phone made by selecting
an option on the phone. The Brave connects the call after set
number of rings. The Brave can be programmed from the
phone following a connection by inputting a password.
Connection between the Brave and a phone made by choosing
an option on the Brave (i.e. Pressing a button).
Signalised when following the dialled number is picked up.
This signal is not available on an analogue line, but the ringing
tone ends and a connection begins. It is difficult to identify the
exact moment this occurs.
Function for relay connections by inputting a combination of up
to 4 buttons or keyboard keys (after pressing the key symbol)
between Doorphone Brave and the electric lock can be
connected code relay (COSW - CodeSwitch), which is located
at the lock and lock activates only when is the same the
specified serial combination of the Brave and set the code on
the board relay (COSW).
Combination of 1-2-or-4 buttons or 10 keyboard keys (after
pressing the key symbol) for a relay connection. External =
being input on the Brave outside the building
Digits combination dial from phone for relay activation (DTMF).
Internal = dial by phone – inside building ( phone connected to
other PBX extension)
BRAVE SlimDP – User and service manual 7
