3 Door Entry System Operation

The Brave SlimDP door entry system's functions are set by establishing
parameters (see the chapter on parameter programming page 23).

3.1 Signalling overview

Brave SlimDP acoustic signals that occur during its operation. Samples
of sounds can be listened to in the setting programme 'BraveSet'.
State
Pick up line type 1
Disconnection of line type 1
Pick up line type 2
Disconnection of line type 2
Confirmation of command from the phone
Ticking during a call
Notice about the end of a call
Relay switch signal
Entry into programming from the phone
Programming from the phone
Parameter confirmation
Entry into programming from the PC
Line connection (Reset)
Error (generally something is not right)
Empty memory (no number is programmed)
It is useful to know what tones the Brave SlimDP plays during
installation as it will assist in the analysis of its state and operation. The
sounds can be turned off in several levels (parameters 61,62,63 and 65).

3.2 Caller at the door

The door entry system's buttons are labelled in the same way as normal
doorbell buttons. Visitor finds the appropriate name (for example Mr Smith)
BRAVE SlimDP –
User and service manual
Tones
–▄■▄■▀–
–▀■▄■▄–
–▄■▀–
–▀■▄–
––█––
─┴─┴─
–■–■–■–
─▒▒▒▒▒▒─
–▄■▀–
––▓–▓–––––
––█––
–▄■▀–
–■–▄–■–
–■–■–■–■–■–
■–
–▄■▄■▄■▄■–
Tone frequency
980-1333-1650
1650-1333-980
800-1067-1200-1333
1333-1200-1067-800
800
1333
Modulated
980-1067-1180
Modulated
800
980-1067-1180
1850-1067-1850
800
1300-2100
