1-2 Ordering Code

1-2 Ordering Code
P41-
P91-
Power Input Power Input
4: 90 - 250 VAC, 47-63 Hz 4: 90 - 250 VAC, 47-63 Hz
5: 11 - 26 VAC or VDC, 5: 11 - 26 VAC or VDC,
SELV, Limited Energy SELV, Limited Energy
Signal Input Signal Input
1: Standard Input 1: Standard Input
Thermocouple: Thermocouple:
J, K, T, E, B, R, S, N, L, J, K, T, E, B, R, S, N, L,
C, P C, P
RTD: PT100 DIN, PT100 JIS RTD: PT100 DIN, PT100 JIS
Voltage: 0-60mV Voltage: 0-60mV
5: 0-10V, 0-1V, 0-5V, 1-5V 5: 0-10V, 0-1V, 0-5V, 1-5V
6: 0-20/4-20 mA 6: 0-20/4-20 mA
9: Special Order 9: Special Order
Output 1 Output 1
0: None 0: None
1: Relay rated 2A/240VAC 1: Relay rated 2A/240VAC
2: Pulsed voltage to drive SSR, 2: Pulsed voltage to drive SSR,
5V/30mA 5V/30mA
3: Isolated 4 - 20mA / 0 - 20mA 3: Isolated 4 - 20mA / 0 - 20mA
4: Isolated 1 - 5V / 0 - 5V/0 - 10V 4: Isolated 1 - 5V / 0 - 5V/0 - 10V
6: Triac output 1A / 240VAC,SSR 6: Triac output 1A / 240VAC,SSR
C: Pulsed voltage to drive SSR, C: Pulsed voltage to drive SSR,
14V/40mA 14V/40mA
9: Special order 9: Special order
Output 2 Output 2
0: None 0: None
1: Relay rated 2A/240VAC 1: Relay rated 2A/240VAC
2: Pulsed voltage to drive SSR, 5V/30mA 2: Pulsed voltage to drive SSR, 5V/30mA
3: Isolated 4 - 20mA / 0 - 20mA 3: Isolated 4 - 20mA / 0 - 20mA
4: Isolated 1 - 5V / 0 - 5V/0 - 10V 4: Isolated 1 - 5V / 0 - 5V/0 - 10V
6: Triac output 1A / 240VAC,SSR 6: Triac output 1A / 240VAC,SSR
7: Isolated 20V/25mA transducer power supply 7: Isolated 20V/25mA transducer power supply
8: Isolated 12V/40mA transducer power supply 8: Isolated 12V/40mA transducer power supply
A: Isolated 5V/80mA transducer power supply A: Isolated 5V/80mA transducer power supply
C: Pulsed voltage to drive SSR, 14V/40mA C: Pulsed voltage to drive SSR, 14V/40mA
9: Special order 9: Special order
0
0: Panel mount IP50 standard 0: Panel mount IP50 standard
1: Panel mount IP65 water resistant 1: Panel mount IP65 water resistant
2: DIN rail mount with IP50 2: DIN rail mount with IP50
3: DIN rail mount with IP65 3: DIN rail mount with IP65
Output 5 Output 5
0: None 0: None
3: Retransmit 4 - 20mA / 0 - 20mA 3: Retransmit 4 - 20mA / 0 - 20mA
4: Retransmit 1 - 5V / 0 - 5V/0 - 10V 4: Retransmit 1 - 5V / 0 - 5V/0 - 10V
7: Isolated 20V/25mA 7: Isolated 20V/25mA
8: Isolated 12V/40mA 8: Isolated 12V/40mA
A: Isolated 5V/80mA A: Isolated 5V/80mA
D: Isolated RS-485 interface D: Isolated RS-485 interface
E: Isolated RS-232 interface E: Isolated RS-232 interface
Output 4 Output 4
0: None 0: None
1: Relay rated 2A/240VAC 1: Relay rated 2A/240VAC
2: Pulsed voltage to drive SSR, 5V/30mA 2: Pulsed voltage to drive SSR, 5V/30mA
3: Retransmit 4 - 20mA / 0 - 20mA 3: Retransmit 4 - 20mA / 0 - 20mA
4: Retransmit 1 - 5V / 0 - 5V/0 - 10V 4: Retransmit 1 - 5V / 0 - 5V/0 - 10V
6: Triac output 1A / 240VAC,SSR 6: Triac output 1A / 240VAC,SSR
7: Isolated 20V/25mA 7: Isolated 20V/25mA
transducer power supply transducer power supply
8: Isolated 12V/40mA 8: Isolated 12V/40mA
transducer power supply transducer power supply
A: Isolated 5V/80mA A: Isolated 5V/80mA
transducer power supply transducer power supply
C: Pulsed voltage to drive SSR, 14V/40mA C: Pulsed voltage to drive SSR, 14V/40mA
9: Special order 9: Special order
Output 3 Output 3
0: None 0: None
1: Relay rated 2A/240VAC 1: Relay rated 2A/240VAC
2: Pulsed voltage to drive SSR, 5V/30mA 2: Pulsed voltage to drive SSR, 5V/30mA
6: Triac output 1A / 240VAC,SSR 6: Triac output 1A / 240VAC,SSR
7: Isolated 20V/25mA transducer power supply 7: Isolated 20V/25mA transducer power supply
8: Isolated 12V/40mA transducer power supply 8: Isolated 12V/40mA transducer power supply
A: Isolated 5V/80mA transducer power supply A: Isolated 5V/80mA transducer power supply
C: Pulsed voltage to drive SSR, 14V/40mA C: Pulsed voltage to drive SSR, 14V/40mA
9: Special order 9: Special order
UM0P411C
Standard leave blank Standard leave blank
Special Order AA-ZZ Special Order AA-ZZ
Options
rubber installed rubber installed
(for P91 only) (for P91 only)
(for P91 only) (for P91 only)
transducer power supply transducer power supply
transducer power supply transducer power supply
transducer power supply transducer power supply
