Mounting
4.4 Mounting and connecting
3. Then carefully lever the insert out of the chromatograph as shown in the following picture.
4. Connect the Ethernet connection of the HMI PC to the corresponding pins of the
Pin No.
22
23
24
25
1)
2)
Following completion of on-site operation
1. Screw in the securing ring as far as possible.
68
A 25-contact Sub-D socket becomes visible.
chromatograph according to the following table. If the display board is removed, the
Ethernet connection via the standard cable is interrupted.
Description
Ethernet 10BaseT TX+
Ethernet 10BaseT TX-
Ethernet 10BaseT RX+
Ethernet 10BaseT RX-
Standard EIA/TIA-T568A assignment
Standard EIA/TIA-T568B assignment
Mounting with hub
1)
Ethernet cable:
Orange/white
Ethernet cable:
Orange
Ethernet cable: Green/white
Ethernet cable:
Green
Operating Instructions, 06/2012, C79000-G5376-C560-07
Comment
Mounting without hub
Ethernet cable:
Green/white
Ethernet cable:
Green
Ethernet cable:
Orange/white
Ethernet cable:
Orange
2)
MicroSAM
