Description
3.6 Functions
The LEDs behind the inspection window of your chromatograph provide you with an initial
overview of the status of your gas chromatograph. They have the following meanings:
LED
Power
Heartbeat
Ready
Maint. Req.
Failure
Sample flow
Health status (left)
Health status (right)
The text box displays the following information:
1. Sample stream: S1, S2, S3, S4
2. Sample components: e.g. CO
3. Measured value of sample as numeric value
52
Meaning if the LED lights up
24 V supply voltage present.
Software sign-of-life
Chromatograph is ready.
Chromatograph has a maintenance request.
Chromatograph has an alarm.
No sample flow
Ethernet connection has been established.
Communication is taking place.
, propane etc.
2
