3.6.5.4

Empty sample loop completely

Time switching point t
membrane valve function 3 (Backflush).
Live
eLive
MV1
Flush loop
ON
MV1
Flush loop_1
ON
MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
= 1.5 s: Following an injection, the injection loop is briefly emptied via
7
MV2
Sample
ON
MV2 MV3
Sample Backflush
ON ON / Pulse 0.2 s
MV3
Backflush
ON / Pulse 0.2 s
MV4
Injection
OFF
Description
3.6 Functions
MV4
Injection
OFF
MV5
Flush loop_2
ON
43
