Release version base device and the associated explosion protection
Release New features of the basic device
version
base
device
AS 08 Live dosing, range of supply
voltage extended:
24 V DC (18.5 V ... 30.2 V)
AS 09 eLive injection: Introduction of a
5th solenoid valve, modification
of the micro-diaphragm valve
AS 10 Modified 3rd temperature control
system (model with temperature
protection)
Modified 4th temperature control
system (model with temperature
protection)
2.4.2

Directives for operation

Switching on the chromatograph
Only switch on the power supply to the device if this has been closed correctly.
MicroSAM
Operating Instructions, 06/2012, C79000-G5376-C560-07
Protection against explosion
ATEX II 2 G EEx d IIC T4
FM
Class I, Div 1, Groups A, B, C, D T4
Class I, Zone 1, Group IIC T4
CSA
Class I, Div 1, Groups B, C, D T4
Enclosure Type 4X
ATEX II 2 G EEx d IIC T4
FM
Class I, Div 1, Groups A, B, C, D T4
Class I, Zone 1, Group IIC T4
CSA
Class I, Div 1, Groups B, C, D T4
Enclosure Type 4X
ATEX
II 2G Ex d IIC T4 Gb
DMT 03 ATEX E 069 X
CSA
CLASS I, DIVISION 1 GROUPS B, C,
D T4
CLASS I, ZONE 1 GROUPS IIC T4
ENCLOSURE TYPE 4X / IP65
General information
2.4 Protection against explosion
Explosion protection certificate
Supplements
ATEX
DMT 03 ATEX E 069 X
Supplement 1 to 3
FM
Certificate 3017424
Date Issued 2005/12/14
CSA
Certificate 1915614
Date Issued 2007/06/07
ATEX
DMT 03 ATEX E 069 X
Supplement 1 to 3
FM
Certificate 3017424
Date Issued 2005/12/14
CSA
Certificate 1915614
Date Issued 2007/06/07
ATEX
DMT 03 ATEX E 069 X
Supplement 1 to 4
FM Certificate canceled
CSA
Certificate 1915614
Date Issued 2009/11/13
